Hibernate（78）如何在GraphQL服务中使用Hibernate？

在GraphQL服务中使用Hibernate是一个有趣且强大的组合。你可以利用Spring Boot和Hibernate来处理数据持久化，并使用Spring Boot的GraphQL模块实现GraphQL API。下面我们详细说明如何实现这一目标。

1. 项目依赖

首先，我们需要在pom.xml中添加必要的依赖，包括Spring Boot、Hibernate、MySQL和GraphQL的依赖。

<dependencies>
    <!-- Spring Boot Starter Data JPA -->
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-data-jpa</artifactId>
    </dependency>
    <!-- MySQL Connector -->
    <dependency>
        <groupId>mysql</groupId>
        <artifactId>mysql-connector-java</artifactId>
        <version>8.0.26</version>
    </dependency>
    <!-- HikariCP for Connection Pooling -->
    <dependency>
        <groupId>com.zaxxer</groupId>
        <artifactId>HikariCP</artifactId>
        <version>4.0.3</version>
    </dependency>
    <!-- Spring Boot Starter Web -->
    <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-web</artifactId>
    </dependency>
    <!-- Spring Boot Starter GraphQL -->
    <dependency>
        <groupId>com.graphql-java-kickstart</groupId>
        <artifactId>graphql-spring-boot-starter</artifactId>
        <version>11.1.0</version>
    </dependency>
    <!-- GraphQL Java Tools -->
    <dependency>
        <groupId>com.graphql-java-kickstart</groupId>
        <artifactId>graphql-java-tools</artifactId>
        <version>11.1.0</version>
    </dependency>
    <!-- Lombok -->
    <dependency>
        <groupId>org.projectlombok</groupId>
        <artifactId>lombok</artifactId>
        <version>1.18.20</version>
        <scope>provided</scope>
    </dependency>
</dependencies>

2. 配置数据源和Hibernate属性

在application.properties中配置MySQL数据源：

# MySQL Database Configuration
spring.datasource.url=jdbc:mysql://localhost:3306/mydatabase
spring.datasource.username=root
spring.datasource.password=rootpassword
spring.datasource.driver-class-name=com.mysql.cj.jdbc.Driver
# Hibernate Configuration
spring.jpa.hibernate.ddl-auto=update
spring.jpa.show-sql=true
spring.jpa.properties.hibernate.dialect=org.hibernate.dialect.MySQLDialect

3. 创建领域模型

Product.java

import lombok.Data;
import javax.persistence.*;
@Data
@Entity
@Table(name = "products")
public class Product {
    @Id
    @GeneratedValue(strategy = GenerationType.IDENTITY)
    private Long id;
    private String name;
    private String description;
    private double price;
}

4. 创建仓储接口

ProductRepository.java

import org.springframework.data.jpa.repository.JpaRepository;
public interface ProductRepository extends JpaRepository<Product, Long> {
}

5. 创建服务层

ProductService.java

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import org.springframework.transaction.annotation.Transactional;
import java.util.List;
@Service
public class ProductService {
    @Autowired
    private ProductRepository productRepository;
    public List<Product> getAllProducts() {
        return productRepository.findAll();
    }
    public Product getProductById(Long id) {
        return productRepository.findById(id).orElse(null);
    }
    @Transactional
    public Product createProduct(Product product) {
        return productRepository.save(product);
    }
    @Transactional
    public Product updateProduct(Long id, Product productDetails) {
        Product product = productRepository.findById(id).orElse(null);
        if (product != null) {
            product.setName(productDetails.getName());
            product.setDescription(productDetails.getDescription());
            product.setPrice(productDetails.getPrice());
            return productRepository.save(product);
        }
        return null;
    }
    @Transactional
    public void deleteProduct(Long id) {
        productRepository.deleteById(id);
    }
}

6. 创建GraphQL Schema

在src/main/resources/graphql目录下创建一个GraphQL schema文件schema.graphqls：

type Product {
    id: ID!
    name: String!
    description: String
    price: Float!
}
type Query {
    products: [Product!]!
    product(id: ID!): Product
}
type Mutation {
    createProduct(name: String!, description: String, price: Float!): Product!
    updateProduct(id: ID!, name: String, description: String, price: Float): Product!
    deleteProduct(id: ID!): Boolean!
}

7. 创建GraphQL Resolvers

ProductQueryResolver.java

import com.coxautodev.graphql.tools.GraphQLQueryResolver;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;
import java.util.List;
@Component
public class ProductQueryResolver implements GraphQLQueryResolver {
    @Autowired
    private ProductService productService;
    public List<Product> getProducts() {
        return productService.getAllProducts();
    }
    public Product getProduct(Long id) {
        return productService.getProductById(id);
    }
}

ProductMutationResolver.java

import com.coxautodev.graphql.tools.GraphQLMutationResolver;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;
@Component
public class ProductMutationResolver implements GraphQLMutationResolver {
    @Autowired
    private ProductService productService;
    public Product createProduct(String name, String description, double price) {
        Product product = new Product();
        product.setName(name);
        product.setDescription(description);
        product.setPrice(price);
        return productService.createProduct(product);
    }
    public Product updateProduct(Long id, String name, String description, double price) {
        Product productDetails = new Product();
        productDetails.setName(name);
        productDetails.setDescription(description);
        productDetails.setPrice(price);
        return productService.updateProduct(id, productDetails);
    }
    public boolean deleteProduct(Long id) {
        productService.deleteProduct(id);
        return true;
    }
}

8. 创建Spring Boot应用主类

Application.java

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
@SpringBootApplication
public class Application {
    public static void main(String[] args) {
        SpringApplication.run(Application.class, args);
    }
}

9. 运行应用

1. 启动MySQL：确保你的MySQL数据库运行在localhost:3306。
2. 创建数据库：创建一个名为mydatabase的数据库。
3. 启动Spring Boot应用：运行Spring Boot应用程序。

mvn spring-boot:run

10. 测试GraphQL API

你可以使用GraphiQL或Postman来测试你的GraphQL API。GraphiQL是一个非常方便的图形化工具，可以直接在浏览器中发送GraphQL查询。

查询所有产品

query {
  products {
    id
    name
    description
    price
  }
}

查询单个产品

query {
  product(id: 1) {
    id
    name
    description
    price
  }
}

创建产品

mutation {
  createProduct(name: "Laptop", description: "A high-end gaming laptop", price: 1500.00) {
    id
    name
    description
    price
  }
}

更新产品

mutation {
  updateProduct(id: 1, name: "Gaming Laptop", description: "An updated high-end gaming laptop", price: 1600.00) {
    id
    name
    description
    price
  }
}

删除产品

mutation {
  deleteProduct(id: 1)
}

总结

通过上述步骤，我们展示了如何在Spring Boot中使用Hibernate创建一个GraphQL服务，包括定义领域模型、创建仓储接口、实现服务层、定义GraphQL schema和创建GraphQL resolvers。在GraphQL服务中，Hibernate可以很好地处理持久化，从而实现清晰的业务逻辑和持久化逻辑分离。
